OneUp
OneUp 104 BCD Traction Chainring
OneUp 104 BCD Traction Chainring
NEW - NOW AVAILABLE IN 30T - Using unique countersunk spacers and M5 Torx bolts OneUp has developed the only 30T ring that works with all 104BCD cranks.
Features:
- Get ultimate traction by smoothing out the torque you deliver to your rear tire
- Narrow Wide tooth profile eliminates chain drop with the perfect chain mesh fit
- Perfect chainline with built in offset. For a quieter drivetrain with improved chain wear and best drop performance
- Reuse your existing 8-10mm long ring hardware - No new bolt packs required
- Aggressive crud chamfers for awesome mud shedding performance and extended ring life
- Reinforced Wide tooth design provides maximum ring durability when run without a bash
- Made from hard wearing 7075-T6 aluminum plate
- 32T rings have integrated shims and M8 chainring bolt threads
- 30T rings have integrated shims and M5 chainring bolt threads to allow the smallest ring size possible on a 104 BCD crank. Bolts and spacers included.
Specification:
- Material: 7075-T6
- Weight: 51g (30T), 49g (32T), 51g (34T)
- Compatible with: 9, 10, 11 and 12 Speed SRAM Chains and 104 BCD cranks (not compatible with 12 Speed XTR Chains)
Installation: Align the small bump (small hole on direct mount rings) on the inner edge of the ring with your crank arm
